粉尘清除机

Dust Collector

自动清除板材因砂光而残留下来的粉尘,提高涂装质量。
This machine automatically removes the dust left over from the plate due to sand light thus improving the coating quality.
产品亮点
Highlights
本机吸尘率高,特殊设计集尘罩,配置强力吹风机,可将磨砂粉尘全部收集于机内。
皮带采用条纹系列,厚度3mm,输送采用铝合金外壳齿轮减速马达,采用变频器控制。
除尘进风采用喇叭口设计方式,强制除尘,引风口径Φ90mm。

This machine has high dust absorption rate special design dust collection cover equipped with a strong hairdryer which can collect all the sand dust in the machine.
The belt adopts the stripe series the thickness is 3mm and the transmission adopts the aluminum alloy shell gear deceleration motor and the control adopts the frequency converter.
Dedusting into the wind adopts the horn mouth design method mandatory dedusting lead the air diameter is φ 90mm.

产品参数
Parameter
项目 Item 参数/Paramter
加工宽度 Working width 1300mm
加工厚度 Working thickness 3-80mm
输送电机功率 Feeding motor power 0.75kw,变频调速,Inverter
输送皮带规格 Conveyor belt specification 5080*1320*3mm
总功率 Total power 2.5kw
外形尺寸 Overall dimensions 2500*2200*1700mm
