全精密双滚涂布机

Precision Double Roller Coater

广泛适用于各种木器塑料金属等产品平面涂装,经本机处理过的油漆表面光滑,饱满度好,无色差。
This machine is suitable for all kinds of woodenplasticmetal and other products.The surface of the paint treated by this machine is smoothfull and colorless.
产品亮点
Highlights
均布轮和工作平台的运动由独立螺旋升降机调整稳定性能高。
均布轮和胶轮的运转由独立的变频器和减速电机控制配置进口PU刮刀面漆可选配滚轮刮刀涂膜厚度可控制在5-10g/㎡ 之间。

The movement of the uniform wheel and the working platform is adjusted by an independent screw lifter.
The operation of the uniform cloth wheel and the rubber wheel is controlled by an independent inverter and a decelerating motor and an imported PU scraper is configured. Paint optional roller scraper film thickness can be controlled between 5-10 g/㎡.

产品参数
Parameter
项目 Item 参数/Paramter
加工宽度 Working width 1300mm
加工厚度 Working thickness 3-80mm
输送电机功率 Feeding motor power 1.5kw,变频调速,Inverter
加温功率 Heating power 4kw
总功率 Total power 11kw
外形尺寸 Overall dimensions 1600*2600*1600mm
